1. Serve motor control system is used for timber feeding, guarantees the veneer thickness in a high precision, avoiding blade scratch on the timber
2.Whole beam holds the log strongly, and hydraulic driven hooks clamp the log tightly and effectively. Vacuum disc system is used inside the log beam to help holding the big timber in order to avoid logs deforming or dropping down during cutting procedure
3.All switch button are gathered in a cabinet.Single person can operate the machine avoiding the dangerous caused by fault
4.Special designed big size driving gear runs smoothly with a low noise when it runs in a high speed
Automatic hydraulic blade holding system, and log holder auto turn back system are fitted there, grinding and replacing the blade become so easy and quickly.
|
Place of Origin |
Shandong,China |
|
Condition |
New |
|
Type |
Veneer Slicer |
|
Weight(KG) |
25000kg |
|
Applicable Industries |
Woodworking veneer slicer |
|
Warranty |
1 Year |
|
Key Selling Points |
High-accuracy |
|
Use |
Plywood Production |
|
Brand Name |
Sinoeuro |
|
Voltage |
380V/415V |
|
Dimension(L*W*H) |
8030×4530×2530mm |
|
Power(kw) |
40KW |
|
Video outgoing-inspection |
Provided |
|
Warranty of core components |
1Year |
|
Core Components |
Motor |
|
Model |
BB1226 |
|
Main motor power |
37kw |
|
Feed motor power |
4.5kw(servo motor) |
|
Clamping motor |
7.5kw |
|
Conveyor motor |
0.75kw |
|
Wood clamping unit |
10units |
|
Spare parts supply |
Will supply st any time |
|
Capacity |
0-36pcs/min |
|
Weight |
28Tons |
